The MXS 5.0 TEST & CHARGE combines an advanced micro-processor controlled battery charger with a battery and alternator test function to provide the ultimate in battery testing, charging and maintenance.

Charging - The MXS 5.0 TEST & CHARGE provides excellent performance on batteries from 1.2Ah up to 110Ah. The charger solves a broad range of battery problems and features include a patented automatic desulphation step and a special reconditioning step that will revive and restore deeply discharged and stratified batteries. The patented Float/Pulse maintenance makes the charger ideal for long-term maintenance. The RECOND and COLD WEATHER OPTION operate individually or together in both SMALL BATTERY and NORMAL BATTERY programs providing great flexibility for the user.

Testing - Three easy to use programs to test battery voltage, start power and alternator performance to provide a complete picture of battery and vehicle charging system health.

The MXS 5.0 TEST & CHARGE is easy and safe to use, protects vehicle electronics, spark-free, reverse polarity protected and short circuit proof. The MXS 5.0 TEST & CHARGE features a 5-year warranty.

Features:

• Auto: Fully automatic for optimal charging
• 12V: For all lead-acid batteries
• Step 7: Fully charged battery
• Step 8: Maintenance charging
• COLD/AGM: Charging in cold conditions and AGM batteries
• RECOND: Recondition of deeply discharged batteries
• BATTERY: Test battery voltage
• START POWER: Test battery starting power
• ALTERNATOR: Test alternator charging performance
• Volt 12V
• Rated Voltage AC 220–240VAC, 50–60Hz
• Charging voltage SMALL, NORMAL: 14.4V, COLD/AGM: 14.7V, RECOND: 15.8V
• Min battery voltage 2.0V
• Charging current 5A max
• Current, mains 0.65A rms (at full charging current)
• Back current drain <1Ah/month
• Ripple <4%
• Ambient temperature -20°C to +50°C, output power is reduced automatically at high temperatures
• Charger type 8 step, fully automatic charging cycle with adjustable parameters
• Battery types All types of 12V lead-acid batteries (WET, MF, Ca/Ca, AGM and GEL)
• Battery capacity 1.2–110Ah up to 160Ah for maintenance
• Dimensions 168 x 65 x 38mm (L x W x H)
• Insulation class IP65
• Weight 0.6kg
